TE Connectivity 171825-2 EI Series Pin Strip 2 Pins 2.50 Mm Spacing

TE Connectivity
Order Code:

07-3795

Brand: TE Connectivity MPN: 171825-2 EAN-13: 2050003625722
Qty Unit Price (Ex VAT)
20+ £0.290
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
320 in stock, despatched in 4 working days

TE Connectivity's 171825-2 is a board connector with a male configuration featuring 2 contacts in a single row.

This unshrouded connector is designed for easy integration into electronic circuitry.

It is commonly used in applications requiring a simple connection interface on printed circuit boards.

The component is suited for quick prototyping and assembly due to its straightforward and open design.


Type Pin strip (standard)
Number of Positions 2
Pitch 2.5mm
Number of Rows 1
Approvals UL
AWG 22
Backwall/Post Interruptions No (Without)
Board contact surface Tin plated
Case Material Polyamide
Centerline (Pitch) 5.0038mm
Circuit Application Signal
Color Natural
Colour Ecru
Compatible With Agency/Standards Products UL
Connection Print
Connector & Contact Terminates To Printed Circuit Board
Connector contact surface Tin plated
Connector Height .409
Connector Mounting Type Board Mount
Connector orientation Perpendicular (to the PCB)
Connector Product Type Connector Assembly
Connector Profile Low
Connector System wire-to-wire
Connector Type Plug, straight
Contact Base Material Brass
Contact Current Rating 3.5a
Contact Current Rating (Max) 5
Contact Finish - Mating TIN
Contact Gender Male
Contact Material Copper alloy
Contact Mating Area Length .295
Contact Mating Area Plating Material Tin (Sn)
Contact Mating Area Plating Material Thickness 31.49
Contact Mating Length 7.5mm
Contact Plating Copper, Tin
Contact Retention No (Without)
Contact Shape Square
Contact Shape & Form Square
Contact Type Pin
Cross Section 2.50mm
DC Rated Voltage 350v
Depth 5.3mm
Dimensions (L x W x H) 4.9 x 14.0 x 5 mm
ELV Compliant
Flammability Rating UL94 V-0
Gender Male
Header Type Partially Shrouded
Height 5mm
Housing Color Natural
Housing Material 6/6 Nylon
Industrial packaging No
Insulation Color Natural
Insulation Material Polyamide
Lead Free Lead Free
Length 4.9mm
Mating Alignment With
Mating Alignment Type Polarization
Mating Retention With
Mating Retention Type Polarized Lock
Mating Square Post Dimension .025
Max Operating Temperature 95°C
Max Voltage Rating (AC) 250v
Max Voltage Rating (DC) 350.25kV
max. cross section 0.33mm²
Max. temperature +95°C
Min Operating Temperature -20°C
Min. cross section 0.08mm²
Min. temperature -20°C
Misc Attribute EI
Mount Through Hole
Nominal Current 3.5A
Nominal Voltage 250V AC
Number of Contacts 2
Operating Temperature Range -4 – 203
Operating Voltage 250
Orientation Straight
Package Quantity 1000
Packaging Bag
Packaging Method Box
Packaging Quantity 1000
Panel Mount Feature Without
PCB Connector Type PCB Mount Header
PCB Contact Termination Area Plating Material Tin
PCB Contact Termination Area Plating Material Thickness .8
PCB Mount Alignment Without
PCB Mount Orientation Vertical
PCB Mount Retention With
PCB Mount Retention Type Retention Solder Tails
PCB Mounting Orientation Vertical
PCB Thickness 0.063inch
PCB Thickness (Recommended) .063
Pin Ø 0.64mm
Pin shape Rectangular
Pins per row 2
Plating Thickness 0.8um
Primary Product colour Natural
Radiation Hardening No
Reach SVHC Compliant No
RoHS Compliant Yes
Sealable No
Series EI Series
Square Termination Post & Tail Dimension .025
Strain Relief No (Without)
Tail Length 0.142inch
Termination Solder
Termination Method to PCB Through Hole - Solder
Termination Post & Tail Length .142
UL Flammability Rating UL 94V-0
Voltage Rating 350v
Voltage Rating (AC) 250v
Width 14.0mm
