TE Connectivity 1658527-7 is an unshrouded female connector with 16 positions and 30 micro-inch gold plating.
It is designed for robust and reliable electrical connections.
This connector is typically used in industrial applications and electronic equipment.
The product ensures durability and consistent performance in demanding environments.
| Type |
Female cable Mount IDC Connector |
| Number of Ways |
16 |
| Pitch |
2.54mm |
| Number of Rows |
2 |
| Mounting Type |
Cable (IDC) |
| Strain Relief |
Not Specified |
| Board contact surface |
Tin plated |
| Case Material |
Thermoplastic |
| Centerline (Pitch) |
2.54mm |
| Circuit Application |
Signal |
| Coating thickness (PCB side) |
1.27µm |
| Color |
Blue |
| Colour |
Blue |
| Connection |
Cut & Clip |
| Connector & Contact Terminates To |
Wire & Cable |
| Connector & Housing Type |
Receptacle |
| Connector coating thickness |
0.76µm |
| Connector contact surface |
Gold plated |
| Connector Mounting Type |
Cable Mount (Free-Hanging) |
| Connector Product Type |
Connector Assembly |
| Connector System |
Wire-to-Board |
| Connector Type |
Power strip |
| Contact Current Rating |
1a |
| Contact Current Rating (Max) |
1 |
| Contact Gender |
Female |
| Contact Material |
Phosphor bronze |
| Contact Mating Area Plating Material |
Gold (Au) |
| Contact Mating Area Plating Material Thickness |
30 |
| Contact Plating |
Gold |
| Contact Type |
Female Socket |
| Cross Section |
2.54mm |
| Current Rating |
1a |
| Depth |
7.05mm |
| Dimensions |
(L x W x H) 19.05 x 6.05 x 14.15 mm |
| ELV |
Compliant |
| Flammability Rating |
UL94 V-0 |
| Gender |
Receptacle |
| Height |
14.15mm |
| Housing Color |
Blue |
| Length |
19.05mm |
| Material |
Glass, Thermoplastic |
| Mating Alignment Type |
Polarization |
| Mating cycles |
200 |
| Mating Retention |
Without |
| Mating Square Post Dimension |
.025 |
| Max Operating Temperature |
125°C |
| Max. temperature |
+125°C |
| Min Operating Temperature |
-55°C |
| Min. temperature |
-55°C |
| Mount |
Free Hanging, Cable, Through Hole |
| Nominal Current |
1A |
| Nominal Voltage |
250V AC |
| Number of Contacts |
16 |
| Number of Poles |
16 |
| Number of Positions |
16 |
| Operating Temperature Range |
-67 – 257 |
| Orientation |
Right Angle |
| Package Quantity |
50 |
| Packaging |
Bulk |
| Pins per row |
8 |
| Primary Product colour |
Blue |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
Unknown |
| RoHS Compliant |
Yes |
| Row Spacing |
2.54mm |
| Row-to-Row Spacing |
.1 |
| Series |
AMP-LATCH 622 |
| Termination |
IDT |
| Termination Method to Wire & Cable |
Insulation Displacement (IDC) |
| Total number of pins |
16 |
| Voltage Rating |
500v |
| Width |
6.05mm |
| Wire Gauge (Max) |
28AWG |
| Wire Gauge (Min) |
26AWG |
| Wire/Cable Type |
Ribbon |
