The TE Connectivity 164581-000 ring terminal is designed for use with 12-10 AWG wires and features a yellow colour for easy identification.
It includes a shrinkable insulation sleeve for enhanced protection and durability.
This component is commonly used in automotive and industrial applications for secure electrical connections.
The ring terminal is suitable for applications requiring a #8 stud size.
| Colour |
Yellow |
| Insulated |
Partially Insulated |
| Stud Size |
Not Specifiedmm |
| Maximum Wire Size (mm2) |
6mm² |
| Barrel Type |
Closed |
| Body Material |
Copper |
| Body Plating |
Tin |
| Color |
Yellow |
| Contact Material |
Copper Alloy |
| Contact Plating |
Tin |
| Depth |
7.87mm |
| Government Qualified |
No |
| Heavy Duty |
No |
| Insulated Wire Support |
Yes |
| Insulation |
Insulated |
| Insulation Diameter |
6.35mm |
| Insulation Material |
Nylon |
| Length |
1.496inch |
| Material |
Copper |
| Max Operating Temperature |
125°C |
| Maximimum Wire Gauge (AWG) |
10 |
| Min Operating Temperature |
-55°C |
| Mount |
Free Hanging |
| Number of Holes |
1 |
| Operating Temperature Range |
-67 – 257 |
| Package Quantity |
500 |
| Packaging |
Bulk |
| Packaging Method |
Package |
| Packaging Quantity |
500 |
| Plating |
Tin |
| Product Length |
1.496 |
| Product Type |
Ring Terminal |
| Product Weight |
.03527 |
| Radiation Hardening |
No |
| RoHS Compliant |
Yes |
| Sealable |
No |
| Series |
Dura-Seal |
| Stud Diameter |
4.3mm |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Termination |
Circular |
| Tongue Thickness |
0.039inch |
| Wire Gauge (Max) |
12AWG |
| Wire Gauge (Min) |
10AWG |
| Wire Insulation Support |
With |
