TE Connectivity 1393236-1 General Purpose Relay 12V 30A SPST PCB

Inc VAT

Qty	Unit Price (Ex VAT)
40+	£7.70

Sign in for personalised pricing

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 40

Despatched within 5 working days - 1,482 in stock

The TE Connectivity 1393236-1 is a general purpose relay featuring a single pole single throw (SPST) configuration.

It operates at 12V with a current capacity of 30A, making it suitable for various electrical applications.

This relay is designed for use on printed circuit boards (PCB), ensuring ease of installation and stable performance.

It is typically employed in automotive, industrial, and consumer electronics sectors.

Coil Voltage	12V DC
Contact Configuration	SPST (to be defined)
Switching Current	30A
Coil Current	34mA
Coil Power	170mW
Coil Resistance	147r
Coil Type	Non-Latching
Coil Voltage (DC)	5v
Contact Current Rating	6a
Contact Material	Tin, Silver, Gold
Contact Plating	Gold
Current Rating	6a
Depth	5mm
Dropout Voltage	200mV
ELV	Compliant
Length	28.0mm
Max Current Rating	10a
Max Voltage Rating (AC)	400v
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Mount	Through Hole, PCB
Mounting Type	PCB
Number of Contacts	1
Operate Time	12ms
Package Quantity	1000
Package/Case	SIP
Packaging	Bulk
Ratings	IP67
Relay Type	General Purpose
Release Time	5ms
RoHS Compliant	Yes
Series	SNR, SCHRACK
Termination	PC Pin
Throw Configuration	SPDT
Type	Power Relay
Voltage Rating (AC)	400v
