TE Connectivity 1-967644-1 AMP MQS Socket Housing Cable 2 Pins

TE Connectivity manufactures this AMP MQS socket housing cable, featuring a total of two pins, suited for automotive electrical systems. This connector ensures reliable electrical connections and is typically used in signal and low power applications. Renowned for its durable construction, it is designed to withstand the demanding environments common in automotive setups.

Type	Socket, straight
Number of Contacts	2
Gender	Female
Number of Rows	1
Body Material	PBT
Case Material	Polybutylene
Circuit Application	Signal
Colour	Black
Connector contact surface	Tin plated
Connector System	automotive
Contact Type	Female Socket
Depth	24.15mm
Dimensions	(L x W x H) 17.4 x 24.15 x 15.2 mm
ELV	Compliant
Flammability Rating	UL94 HB
Height	15.2mm
Housing Color	Black
Hybrid Connector	No
Industrial packaging	No
IP Rating	IP69K
Lead Free	Not Applicable
Length	17.4mm
Mating Tab Width	0.025inch
Max Operating Temperature	248°C
Max. temperature	+120°C
Min Operating Temperature	-40°C
Min. temperature	-40°C
Mount	Free Hanging, Cable
Orientation	Straight
Package Quantity	2700
Packaging	Bag
Pins per row	2
Pitch	0.157inch
Polarized	Yes
Primary Type	CONNECTOR
Reach SVHC Compliant	No
RoHS Compliant	Yes
Sealable	Yes (With)
Series	AMP MQS
Serviceable	No
Strain Relief	No (Without)
Termination	Crimp
Width	24.15mm
