TE Connectivity 1-967640-1 AMP MQS Socket 4 Pins 1 pc

MPN: 1-967640-1
Brand: TE Connectivity
EAN-13: 2050003947251
Order Code: 07-3961
Country of Origin: Germany

RoHS Compliant
Free UK shipping available

View Full Product Range (5)

Inc VAT

Qty	Unit Price (Ex VAT)
5+	£1.13
10+	£1.04
100+	£1.01

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Order in multiples of 1

Despatched within 4 working days - 80 in stock

Product Details
Product Range
Data Sheets
Quick Quote

The TE Connectivity 1-967640-1 is a combination line connector featuring four female contacts.

It is designed for robust electrical connections and ensures reliable performance in automotive applications.

This connector offers enhanced durability and secure fitment for various electronic systems.

Typical applications include use in automotive harnesses and electric control units.

Type	Socket, straight
Number of Contacts	4
Gender	Female
Number of Rows	2
Body Material	PBT
Case Material	Polybutylene
Circuit Application	Signal
Colour	Black
Connector contact surface	Tin plated
Connector System	automotive
Contact Type	Female Socket
Depth	24.2mm
Dimensions	(L x W x H) 15.3 x 24.2 x 24.2 mm
ELV	Compliant
Height	24.2mm
Housing Color	Black
Hybrid Connector	No
Industrial packaging	No
IP Rating	IPX9K
Length	15.3mm
Mating Tab Width	0.025inch
Max Operating Temperature	248°C
Max. temperature	+120°C
Min Operating Temperature	-40°C
Min. temperature	-40°C
Mount	Free Hanging
Orientation	Straight
Package Quantity	1700
Packaging	Bag
Pins per row	2
Pitch	3.1mm
Polarized	Yes
Radiation Hardening	No
Reach SVHC Compliant	No
RoHS Compliant	Yes
Row Spacing	0.232inch
Sealable	Yes (With)
Series	AMP MQS
Serviceable	No
Strain Relief	No (Without)
Termination	Crimp
Width	24.2mm
Wire Gauge (AWG)	17AWG
