TE Connectivity 1-770967-1 Mini-Universal-MATE-N-LOK 3-Pin PCB Housing

TE Connectivity
Order Code:

07-3873

Brand: TE Connectivity MPN: 1-770967-1 EAN-13: 2050002432918
Qty Unit Price (Ex VAT)
1+ £5.15
125+ £4.04
250+ £3.51
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
100 in stock, despatched in 4 working days

TE Connectivity's combination line connector, part number 1-770967-1, features three unshrouded male contacts.

It is typically used in electronic and electrical applications for secure connections.

The design ensures reliable performance and easy integration.

This part is ideal for use in automotive and industrial sectors.


Pitch 4.1148mm
No. of Rows 1
No. of Ways 3
Approvals CSA
Board contact surface Tin plated
Case Material Polyamide
Circuit Application Power
Color White
Compatible With Agency/Standards Products CSA
Compatible With Approved Standards Products UL E28476
Connection Print
Connector & Contact Terminates To Printed Circuit Board
Connector Contact Load Condition Fully Loaded
Connector contact surface Gold plated
Connector Height .306
Connector Length .602
Connector Mounting Type Board Mount
Connector Product Type Connector Assembly
Connector System wire-to-wire
Connector Type Plug, horizontal mount
Connector Width .5
Contact Base Material Brass
Contact Current Rating 9.5a
Contact Current Rating (Max) 9.5
Contact Finish Copper alloy
Contact Finish - Mating GOLD
Contact Gender Male
Contact Layout Inline
Contact Material Brass, Tin
Contact Mating Area Plating Material Gold (Au)
Contact Mating Area Plating Material Thickness 30
Contact Plating Gold, Tin
Contact Retention No (Without)
Contact Shape Circular
Contact Shape & Form Round
Contact Type Pin
Contact Underplating Material Nickel
Contact Underplating Material Thickness 50
Current Rating 9.5a
Dim (L x W x H) 7.77 x 14.00 x 12.70 mm
Factory colour White
Flammability Rating UL94 V-0
Glow Wire Rating Standard Part - Not Glow Wire
Header Type Fully Shrouded
Height 12.70mm
Housing Color White
Housing Material Nylon
Industrial packaging No
Insulation Color White
Insulation Material Polyamide
Length 7.77mm
Mating Alignment With
Mating Alignment Type Chamfered Edges
Mating Retention With
Mating Retention Type Locking Tab
Max Operating Temperature 221°C
Max Voltage Rating (AC) 600v
Max. temperature +105°C
Min Operating Temperature -67°C
Min. temperature -55°C
Misc Attribute Mini-Universal MATE-N-LOK
Mount Through Hole
Nominal Current 9.50A
Nominal current - rounded value 9.5A
Nominal Voltage 600V AC
Number of Columns 3
Number of Contacts 3
Number of Ports 1
Number of Positions 3
Number of Power Positions 3
Number of Rows 1
Operating Temperature (Max) 221
Operating Temperature Range -67 – 221
Operating Voltage 600
Orientation Right Angle
Package Quantity 200
Packaging Bag
Packaging Method Bag
Packaging Quantity 200
Panel Mount Feature Without
PCB Connector Type PCB Mount Header
PCB Contact Termination Area Plating Material Tin
PCB Contact Termination Area Plating Material Finish Matte
PCB Contact Termination Area Plating Material Thickness 150 – 350
PCB Mount Alignment Without
PCB Mount Orientation Right Angle
PCB Mount Retention With
PCB Mount Retention Type Boardlock
PCB Mounting Orientation Right Angle
PCB Thickness 0.062mm
PCB Thickness (Recommended) .062
Pin shape Circular
Pins per row 3
Primary Product colour White
Reach SVHC Compliant Unknown
RoHS Compliant Yes
Sealable No
Series Mini-Universal-MATE-N-LOK
Strain Relief No (Without)
Termination Solder
Termination Method to PCB Through Hole - Solder
Termination Post & Tail Length .145
Type Pin housing PCB
UL Flammability Rating UL 94V-0
UL Rating Recognized
VDE Tested Yes
Voltage Rating 600v
Voltage Rating (AC) 600v
Width 14.00mm
