TE Connectivity's 928931-2 is a connector accessory designed for cables with a minimum diameter of 0.055 inches and a maximum of 0.09 inches.
This product features a robust build quality, ensuring a secure fit and reliable performance.
It is commonly used in applications requiring durable and precise cable management.
Ideal for automotive and industrial environments, the 928931-2 enhances connectivity and cable organisation.
- Product type: Crimp Tab
- Connector type: Tab
- Applies to: Wire/Cable
- Contact plating: Pre-Tin
- Contact plating thickness: 1 µm [ 39.37 µin ]
- Contact base material: CuZn
- Contact current rating (A): 25
- Wire/cable type: Discrete Wire
- Termination method to wire/cable: Crimp
- Insulation diameter: 1.4 to 2.3mm [.055 to.0905 in ]
- Connector system: Wire-to-Wire
- Wire/cable size: .5 - 1mm², 20 - 17 AWG
- Contact design: FASTIN-FASTON
- Contact classification: Power
- Operating temperature range: -40 to +130 °C [ -40 to +266 °F ]
- Packaging quantity: 1
- Mftrs part no. 928931-2
| Insulation |
Non-Insulated |
| Tab Width |
0.11inch |
| Tab Thickness |
0.032inch |
| Gender |
Male |
| Barrel Type |
Open |
| Compatible Insulation Diameter Range |
.055 – .09 |
| Contact Base Material |
Copper Zinc Alloy |
| Contact Material |
CuZn |
| Contact Plating |
Tin |
| Contact Type |
Signal |
| Crimp Type |
F-Crimp |
| Depth |
3.1mm |
| ELV |
Compliant |
| Height |
3.7mm |
| Insulated |
Uninsulated |
| Insulation Diameter |
-2.3mm |
| Insulation Option |
Uninsulated |
| Lead Free |
Not Applicable |
| Length |
22.8mm |
| Mating Retention Type |
Locking Lance |
| Mating Tab Thickness |
.031 |
| Mating Tab Width |
.11 |
| Max Operating Temperature |
-130°C |
| Maximum Wire Size AWG |
20 to 17AWG |
| Min Operating Temperature |
-40°C |
| Mount |
Free Hanging, Cable |
| Mounting Type |
Wire Mount |
| Operating Temperature Range |
-40 – 266 |
| Orientation |
Straight |
| Outer Width |
2.79mm |
| Package Quantity |
1000 |
| Packaging |
Loose Piece |
| Packaging Method |
Box |
| Packaging Quantity |
1000 |
| Plating Thickness |
1um |
| Product Length |
.886 |
| Product Terminates To |
Wire & Cable |
| Radiation Hardening |
No |
| Reach SVHC Compliant |
No |
| RoHS Compliant |
Yes |
| Series |
Fastin-Faston |
| Shielding |
Unshielded |
| Terminal Orientation |
Straight |
| Terminal Plating Material |
Tin |
| Terminal Type |
Crimp Tab |
| Termination |
Crimp |
| Type |
Quick Disconnects |
| Wire Gauge (Max) |
20AWG |
| Wire Gauge (Min) |
17AWG |
| Wire Size |
1021 – 2048 |
| Wire/Cable Gauge |
17AWG |
| Wire/Cable Type |
Discrete |
