TDK-Lambda PXC-M03-24WD12 DC/DC Converter 12V 125mA 5kV Isolation 1piece

The TDK-Lambda PXC-M03-24WD12 is a DC/DC converter designed to provide 12 V output at 125 mA. This compact device is ideal for converting direct current efficiently in various electronic applications. It is commonly used in industrial and telecommunications equipment for reliable power supply.

Number of Outputs	2.0
Output Voltage	12V
Output Current	125mA
Mounting Type	PCB
Dimensions	(L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency	86%
Enclosure	DIP 24
Height	10.2mm
Industry Standard Size	DIP-24
Input Voltage	36V
Input Voltage Range[DC] / Vdc	9 to 36
Insulation Voltage	5000V AC
Isolation	Isolated
Length	31.8mm
Max. output current	125mA
Maximum Operating Temperature	+94°C
Maximum Output Current / A	0.25 0.25
Maximum Output Power / W	3
Minimum Input Volage	9V
Nominal Input Voltage[DC] / Vdc	24
Operating temperature (min.)	-40°C
Option	Pinout style B (No remote ON/OFF & no trim pin)
Output Voltage Range[DC] / Vdc	Fixed Fixed
Package / Mounting	PCB mount
Rated Output Voltage[DC] / Vdc	0
Series	PXC-M
Terminal Style	DIP
Type	DC/DC converter (print)
Weight	14g
Width	20.3mm
