Signal Construct SMTD22038 22mm LED Indicator Lamp Red 230VAC

MPN: SMTD22038
Brand: Signal Construct
EAN-13: 2050000011443
Order Code: 50-2249
Country of Origin: Germany

RoHS Compliant
Free UK shipping available

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£11.95

Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT

Despatched within 4 working days - 20 in stock

Product Details
Product Range
Data Sheets

A red LED indicator that is a panel mounting device with screw fastening that has an IP67 protection rating, making it suitable for both indoor and outdoor use. The lamp is 230V AC powered and has a frosted matt finish that enhances on/off contrast.

Protection type IP67
Internal reflector
Includes milled nut and O ring
Life time 50,000 hours
Connection by screw terminal for wire up to 1.5mm²
M22 body for mounting in a ø22 +0.2mm cut out

Type	LED indicator light
Lamp/Lens Colour	Red
Bezel	Prominent
Brightness (mcd)	250mcd
Current	15mA
IP Rating	IP67
Panel Cutout Size	22.2
Size	22mm
View Angle	160°
Voltage	230V
