Siemens 6ES7222-1AD30-0XB0 S7-1200 SB 1222 Digital Output Module

Image Representative of Range

Siemens 6ES7222-1AD30-0XB0 S7-1200 SB 1222 Digital Output Module

Siemens
Order Code:

55-8155

Brand: Siemens MPN: 6ES72221AD300XB0 EAN-13: 6940408100824
Qty Was Unit Price (Ex VAT)
1+ £67.59 £67.13
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
5 in stock, despatched in 4 working days

The Siemens 6ES7222-1AD30-0XB0 SB 1222 is a Digital Input/ Output Signal Module that convert the internal signal level of the S7-1200 to the external signal level required for the process. The signal module is plugged directly into the receptacle on the front of the S7-1200 CPU and connects electrically and mechanically to the CPU. The CPU mounting dimensions remain unchanged.


  • SPS component (category): SPS add-on module
  • Voltage: 5V DC
  • Current: 0.1A
  • Load resistance: 5Ω
  • Temperature range: -40°C to +70°C
  • Dimensions: 38(W) x 62(H) x 21(H)mm
  • Weight: 40g
  • Specification: 4 DA, 5V/DC, 200kHz
  • Type: Digital Output Module
  • Manufacturer's part: 6ES7222-1AD30-0XB0 S7-1200 SB 1222
Appendant operation agent (Ex ia) false
Appendant operation agent (Ex ib) false
Depth 21mm
Digital inputs configurable true
Digital outputs configurable true
Display No
Explosion safety category for dust N/A
Explosion safety category for gas N/A
Height 62mm
Input current at signal 1 N/A
Module type Analog
Number of Analogue Inputs 0
Number of Analogue Outputs 0
Number of Digital Inputs 0
Number of Digital Outputs 4
Operating Voltage 5V DCV
Output Current 0.1A
Package depth 30mm
Package height 81mm
Package width 51mm
Performance level according to EN ISO 13849-1 N/A
Permitted voltage at input N/A
Permitted voltage at output 4.25 - 6V
Power Consumption N/A
Product colour Multicolour
Purpose System power
Redundancy false
Short-circuit protection, outputs available false
SIL according to IEC 61508 N/A
Suitable for safety functions false
Supply voltage AC 50 Hz N/A
Supply voltage AC 60 Hz N/A
Supply voltage DC N/A
Time delay at signal change N/A
Type Add-on module
Type of digital output Transistor
Type of electric connection N/A
Type of output voltage DC
Type of voltage (input voltage) N/A
Voltage 5v dc
Voltage type (supply voltage) DC
Weight 33 g
Width 38mm
