Siemens 5UB4731 Delta Grey PG socket 190/22 277mm 16MW data bus

The Siemens Switch product range includes the PG socket Delta Grey 5UB4731, a reliable wall socket with safety and protective contact features. This double socket outlet provides overvoltage and fault current protection, ideal for ensuring electrical safety in homes and offices. Its earth leakage switch function makes it suitable for environments where electrical fault prevention is crucial.

Type	Switch product range
Anti-bacterial treatment	false
Colour	Grey
Colour of switch operator	N/A
Compatible with Amazon Alexa	false
Compatible with Apple HomeKit	false
Compatible with Google Assistant	false
Compliant with UK Building Regulations Part M	N/A
Concurrently switching neutral conductor	N/A
Connection Type	Push-in clamp
Depth	54mm
Device depth	45mm
Device height	70mm
Device width	70mm
Eject-mechanism	false
Fault current protection	FALSE
For heavy conditions according to VDE	false
Frequency	50 - 50Hz
Halogen free	TRUE
Height	75mm
IFTTT support available	false
Impact strength	Other
Imprint/indication	N/A
Insulated mounting	FALSE
IP Rating	IP44
Label space/information surface	FALSE
Length	75mm
Lockable	FALSE
Material	N/A
Material quality	Thermoplastic
Max. current rating of USB power supply	N/A
Metallic colour	false
Min. depth of built-in installation box	45
Model	Other
Mounting method	Surface mounted (plaster)
Nominal Current	16A
Nominal Voltage	250V
Number of active contacts (flat)	2
Number of active contacts (round)	N/A
Number of active contacts (square)	N/A
Number of loop throughs	N/A
Number of modules (module system)	N/A
Number of Phases	2
Number of ports USB-A	N/A
Number of ports USB-C	N/A
Number of socket outlets switchable	0
Number of units	1
Outlets	3
Overvoltage protection	FALSE
Package depth	82mm
Package height	216mm
Package width	93mm
Protective contact	TRUE
RAL-number (similar)	7035
Rated fault current	N/A
Rotated central insert	FALSE
Size/ Dimensions	(L x W x H) 75 x 198 x 75 mm
Special power supply	No special power supply
Suitable for degree of protection (IP)	IP20
Surface finishing	Glossy
Surface protection	Other
Switch type function	PG socket
Transparent	FALSE
Type of fastening	Mounting with claw and screw
Type series	Delta
Weight	0
Width	198mm
With built-in bluetooth speaker	N/A
With built-in USB power supply	FALSE
With enhanced contact protection	FALSE
With function lighting	FALSE
With hinged lid	TRUE
With loop through function	TRUE
With miniature fuse	FALSE
With on/off switch	FALSE
With orientation lighting	FALSE
With signal lamp	false
With Wi-Fi signal repeater	N/A
