The Siemens 5TT5830-0 is a remote switch with a current rating of 25 A, suitable for various electrical applications. As an electrical contactor, it controls high power circuits remotely and efficiently. Typically used in industrial or commercial settings, it ensures precise operation of electrical machinery.
| Type |
Remote switch |
| Coil Voltage |
230V AC |
| Additional equipment possible |
TRUE |
| Built-in depth |
0mm |
| Contact Current Rating |
25A |
| Contact Type |
4 makers |
| Control voltage (max.) |
230V AC |
| Control voltage (min.) |
230V AC |
| Control voltage range |
230 - 230 V AC |
| Current load |
25A |
| Degree of protection (IP) |
IP20 |
| Depth |
71mm |
| Dimensions |
(W x H x D) 36 x 90 x 71 mm |
| Height |
90mm |
| Hum-free |
false |
| IP Rating |
IP20 |
| Max. incandescent lamp load |
2000W |
| Max. load fluorescent lamp |
N/A |
| Max. load fluorescent lamp (Duo circuit) |
N/A |
| Max. load fluorescent lamp (parallel compensated) |
N/A |
| Misc Attribute |
5TT5830-0 |
| Number of contacts as normally closed contact |
0 |
| Number of contacts as normally open contact |
4 |
| Number of modular spacings |
2 |
| Number of normally closed contacts |
0 |
| Number of normally open contacts |
4 |
| Product colour |
Multicolour |
| Rated excitation voltage |
230-230V |
| Rated operating voltage |
440-440V |
| Rated operation current |
25A |
| Slider for hand switch |
FALSE |
| Switching voltage (max.) |
440V AC |
| Switching voltage (min.) |
440V AC |
| Utilization category according to EN IEC 60947-4-1 |
N/A |
| Voltage type (excitation voltage) |
AC |
| Voltage type (operating voltage) |
AC |
| Weight |
256g |
| Width |
36mm |
| Width in number of modular spacings |
2 |
| With day/night function |
false |
