Siemens 5SV60167KK10 AFDD 10A 230V 6kA 1+N C Circuit Breaker compact 1TE

Siemens
Order Code:

07-0480

Brand: Siemens MPN: 5SV60167KK10 EAN-13: 4001869565057
Qty Unit Price (Ex VAT)
1+ £140.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
61 available to back orderBack-order availability date - 27/12/2025

Siemens offers the 5SV6016-7KK10 AFDD, a 10 A, 230 V, 2-pin fuse designed for electrical safety. This arc fault detection device provides enhanced protection against electrical fires. It is typically used in residential and commercial circuit applications to ensure safety and compliance.
Type AFDD
Fuse Size 1
Current Rating 10A
Voltage Rating - AC 230V
Additional equipment attached at delivery Fire protection switch
Built-in depth 70mm
Colour White
Current limiting class 3
Degree of protection (IP) IP20
Depth 68.5mm
Dim (W x H x D) 18 x 90 x 68.5 mm
Height 90mm
Misc Attribute Fire protection switch-LS combination 230 V
Nominal Voltage 230V
Number of Pins 2
Number of Poles 2
Pollution degree 2
Rated short-circuit breaking capacity according to EN 60898 6kA
Rated short-circuit breaking capacity according to IEC 60947-2 6kA
Rated switch current auxiliary device 6000
Release characteristic C
Release characteristics C
Voltage type AC
Width 18mm
Width in number of modular spacings 1
