Siemens 5SV60166KK13 AFDD 13A 230V 6kA 1+N residual current Breaker

The Siemens AFDD 5SV6016-6KK13 is a two-pin, 13 A arc fault detection device designed for 230 V circuits. It provides enhanced safety with a 0.03 A sensitivity, making it ideal for preventing electrical fires in residential and commercial installations. This device is suitable for use in areas where appliances and wiring may be prone to arc faults, ensuring reliable circuit protection.

Type	AFDD
Current Rating	13A
Voltage Rating - AC	230V
Additional equipment attached at delivery	Fire protection switch
Built-in depth	70mm
Colour	White
Concurrently switching neutral conductor	true
Construction size according to DIN 43880	N/A
Control voltage type auxiliary equipment	AC
Current limiting class	3
Degree of protection (IP)	IP20
Depth	68.5mm
Differential current rating	0.03A
Dim	(W x H x D) 18 x 90 x 68.5 mm
Frequency	50 - 50Hz
Height	90mm
Mounting Type	DIN rail
Nominal Voltage	230V
Number of pins	2
Number of Poles	2
Overvoltage category	N/A
Pollution degree	2
Rated short-circuit breaking capacity according to EN 60898	6kA
Rated short-circuit breaking capacity according to IEC 60947-2	6kA
Rated switch current auxiliary device	6000
Rated voltage	230V
Rated voltage auxiliary device	N/A
Release characteristic	B
Release characteristics	B
Voltage type	AC
Weight	0
Width	18mm
Width in number of modular spacings	1
