The Siemens 5SV33116 5SV3311-6 RCCB is a residual current circuit breaker with a 2-pin design, suitable for 16 A and 0.03 A tolerance at 230 V. Key features include reliable protection against electrical shock and fire hazards. It is typically used in residential, commercial, and industrial electrical systems.
| Type |
RCCB |
| AC input frequency |
50 - 60 Hz |
| AC input voltage |
230 V |
| Additional equipment possible |
TRUE |
| Ambient temperature during operating |
-25 - 45°C |
| Breaking Capacity |
10000 A |
| Built-in depth |
70mm |
| Certification |
EAC, VDE, IMQ, OVE |
| Coil voltage (max) |
230 V |
| Coil voltage (min) |
195 V |
| Connectable conductor cross section multi-wired |
0.75 - 35mm² |
| Connectable conductor cross section solid-core |
0.75 - 35mm² |
| Current Ratng |
0.03A |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 36 x 90 x 70 mm |
| Explosion-proof |
false |
| Factory colour |
Grey |
| Frequency |
50 Hz |
| Height |
90mm |
| Leakage current type |
A |
| Misc Attribute |
Design of the product: Undelayed; Mounting type: DIN rail |
| Mounting method |
DIN rail |
| Nominal current output |
16 A |
| Number of modules |
1 |
| Number of Pins |
2 |
| Number of Poles |
2 |
| Pollution degree |
2 |
| Power loss |
0.4W |
| Product colour |
White |
| RAL-number (similar) |
7035 |
| Rated current |
16A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
6kV |
| Rated insulation voltage Ui |
2000V |
| Rated voltage |
230V |
| Release characteristics |
A |
| Selective protection |
FALSE |
| Short-circuit breaking capacity (Icw) |
10kA |
| Short-time delayed tripping |
FALSE |
| Surge current capacity |
1kA |
| Switch-off capacity |
0.5kA |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Weight |
204 g |
| Width |
36mm |
| Width in number of modular spacings |
2 |
| With interlocking device |
TRUE |
