The Siemens 5SV1316-7KK04 is an RCBO with a 4 A current rating and 0.03 A residual current rating, designed for 230 V systems. It combines overcurrent protection and earth fault protection, ensuring enhanced safety in electrical installations. This device is typically used in residential or small commercial circuits to protect against overloads and prevent electrical fires.
| Type |
RCBO |
| Current Ratng |
0.03A |
| Anti-nuisance tripping version |
TRUE |
| Built-in depth |
70mm |
| Concurrently switching neutral conductor |
TRUE |
| Current limiting class |
3 |
| Degree of protection (IP) |
IP20 |
| Depth |
70mm |
| Differential current rating |
0.03A |
| Dim |
(W x H x D) 18 x 90 x 70 mm |
| Disconnection characteristic |
Undelayed |
| Height |
90mm |
| Leakage current type |
A |
| Misc Attribute |
Switch-off description: without delay |
| Number of Pins |
2 |
| Number of poles (total) |
2 |
| Number of protected poles |
1 |
| Overvoltage category |
2 |
| Pollution degree |
2 |
| Rated impulse withstand voltage Uimp |
4 |
| Rated insulation voltage Ui |
253V |
| Rated short-circuit breaking capacity according to EN 61009 |
6 |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
10kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 |
6 |
| Release characteristic |
C |
| Release characteristics |
C |
| Surge current capacity |
1kA |
| Switch-off capacity |
6 |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Width |
18mm |
| Width in number of modular spacings |
1 |
| With interlocking device |
TRUE |
