The Siemens 5SU1356-6KK10 is a DIN Rail Mountable Residual Current Operated Circuit Breaker (RCCB) of Characteristic Type B. This 10A circuit breaker is suitable for use in three-phase current systems before input circuits with rectifiers. It is not intended for use in DC systems and in networks with operating frequencies other than 50Hz or 60Hz.
With Type B, the tripping characteristic is adapted to suit the increase of leakage currents at higher frequencies in systems with capacitive impedances, thus ensuring greater operating safety.
Applications include frequency converters, medical devices and UPS systems.
- Short-circuit and overload protection
- Error protection in safety measures for protection against electrical shock
- Number of pins: 1+N
- Operating voltage: 230V AC
- Differential current rating: 0.03A
- Nominal current: 10A
- Fuse type (category): RCCB
- Release characteristics: B
- Dimensions: 70(D) x 90(H) x 36(W)mm
- Type: DIN Rail Ground Fault Circuit
- Manufacturer's part: Siemens 5SU1356-6KK10
| Type |
RCCB |
| Ambient temperature during operating |
N/A |
| Anti-nuisance tripping version |
true |
| Built-in depth |
70mm |
| Concurrently switching neutral conductor |
true |
| Connectable conductor cross section multi-wired |
0.75 - 35mm² |
| Connectable conductor cross section solid-core |
0.75 - 35mm² |
| Current limiting class |
3 |
| Current Ratng |
10A |
| Degree of protection (IP) |
N/A |
| Differential current rating |
0.03a |
| Disconnection characteristic |
N/A |
| Flush-mounted installation |
true |
| Frequency |
N/A |
| Leakage current type |
A |
| Number of Pins |
1+N |
| Number of Poles |
1+neutral |
| Number of poles (total) |
2 |
| Number of protected poles |
1 |
| Overvoltage category |
N/A |
| Pollution degree |
2 |
| Power loss |
N/A |
| Product colour |
Multicolour |
| Rated current |
10A |
| Rated fault current |
0.03A |
| Rated impulse withstand voltage Uimp |
4kV |
| Rated insulation voltage Ui |
264V |
| Rated short-circuit breaking capacity according to EN 61009 |
6kA |
| Rated short-circuit breaking capacity according to IEC 60947-2 |
15kA |
| Rated short-circuit breaking capacity Icn according to EN 61009-1 |
6kA |
| Rated voltage |
230V |
| Release characteristic |
B |
| Surge current capacity |
1kA |
| Tripping Characteristics |
B |
| Voltage Rating |
230V |
| Voltage type |
AC |
| Weight |
272 g |
| Width in number of modular spacings |
2 |
| With interlocking device |
true |
