Siemens 5SL65166 SENTRON Circuit Breaker 16A 230V 3+N-pole 6kA

The Siemens circuit breaker model 5SL65166 is a 16 A, 230 V automatic protection device. It is designed for modular installation in electrical distribution systems to prevent overcurrent damage. This miniature circuit breaker is typically used in EB-machines and various machine installations.

Type	Circuit breaker
Current Rating	16A
Voltage Rating - AC	230V AC
Additional equipment possible	TRUE
Ambient temperature during operating	-25 - 45°C
Built-in depth	70mm
Compatible with (details)	SENTRON
Concurrently switching neutral conductor	TRUE
Connectable conductor cross section multi-wired	0.75 - 25mm²
Connectable conductor cross section solid-core	0.75 - 25mm²
Current limiting class	3
Current Ratng	16A
Degree of protection (IP)	IP20
Depth	76mm
Dim	(W x H x D) 36 x 90 x 76 mm
Explosion-proof	false
Factory colour	Grey
Flush-mounted installation	false
Frequency	50-60MHz
Height	90mm
Number of Pins	2
Number of poles (total)	2
Number of protected poles	1
Overvoltage category	3
Pollution degree	2
Power loss	N/A
Rated current	16A
Rated impulse withstand voltage Uimp	N/A
Rated insulation voltage Ui	N/A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	6kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	6kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	6kA
Rated voltage	230V
Release characteristic	B
Release characteristics	B
Voltage Rating	230V
Voltage type	AC
Width	36mm
Width in number of modular spacings	2
