Siemens 5SL41047 Circuit Breaker 1-pin 4A 230/400V short-circuit protection

Siemens manufactures the 5SL41047 circuit breaker, featuring a 1-pin, 4 A capacity suitable for both 230 V and 400 V systems. It is commonly used in residential and commercial settings to protect electrical circuits from overload and short circuits. This circuit breaker is an essential component for maintaining electrical safety in various applications.

Type	Circuit breaker
Voltage Rating - AC	400V AC
No. of Poles	1
Tripping Characteristics	C
Additional equipment possible	true
Ambient temperature during operating	-25 - 55°C
Built-in depth	70mm
Compatible with (details)	SENTRON
Concurrently switching neutral conductor	false
Connectable conductor cross section multi-wired	0.75 - 25mm²
Connectable conductor cross section solid-core	0.75 - 25mm²
Current limiting class	3
Current Ratng	4A
Degree of protection (IP)	N/A
Depth	76mm
Dim	(W x H x D) 18 x 90 x 76 mm
Explosion-proof	false
Factory colour	Grey
Flush-mounted installation	false
Frequency	N/A
Height	90mm
Number of Poles	1
Number of poles (total)	1
Number of protected poles	N/A
Overvoltage category	N/A
Pollution degree	2
Power loss	N/A
Rated current	4A
Rated impulse withstand voltage Uimp	N/A
Rated insulation voltage Ui	N/A
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V	10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V	10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V	10kA
Rated voltage	400V
Voltage Rating	440V
Voltage type	AC
Width	18mm
Width in number of modular spacings	1
