Siemens 3TG10100BB4 magnetic starter 3-pole 335kW Aux Switch 33

Image Representative of Range

Siemens 3TG10100BB4 magnetic starter 3-pole 335kW Aux Switch 33

Siemens
Order Code:

06-9189

Brand: Siemens MPN: 3TG10100BB4 EAN-13: 4011209045057
Qty Unit Price (Ex VAT)
1+ £35.74
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
20 available to back orderBack-order availability date - 11/01/2026

Siemens manufactures the 3TG1010-0BB4 Magnetic Starter, featuring three makers and one breaker. This electrical contactor is essential for reliable motor control applications. It is typically used in industrial environments to manage electric power circuits efficiently.
Type Magnetic starter
Connection Screws
Depth 60mm
Dimensions (W x H x D) 36 x 62 x 60 mm
Height 62mm
Max. temperature +55°C
Min. temperature -25°C
Misc Attribute 3TG1010-0BB4
Number of auxiliary contacts as normally closed contact 0
Number of auxiliary contacts as normally open contact 1
Number of normally closed contacts as main contact 0
Number of normally open contacts as main contact 3
Rated operation current Ie at AC-1, 400 V 20A
Rated operation current Ie at AC-3, 400 V 8.4A
Rated operation power at AC-3, 400 V 4kW
Rated operation power NEMA 3.677493749
Suitable for distribution board TRUE
Type of electrical connection of main circuit Screw connection
Voltage type for actuating DC
Width 36mm
