Siemens 3TG10010BB4 SIRIUS starter 55 kW 400/380V size 6 3-pole phased-out

The Siemens 3TG1001-0BB4 is a magnetic starter designed for reliable control of electric motors. This electrical contactor features robust build quality suitable for various industrial applications. It is typically used in automation systems and machinery to ensure smooth motor operation.

Type	Magnetic starter
Auxiliary contact type	1 breaker
Connection	Screws
Contact Type	3 makers
Depth	60mm
Dimensions	(W x H x D) 36 x 62 x 60 mm
Height	62mm
Max. temperature	+55°C
Min. temperature	-25°C
Misc Attribute	3TG1001-0BB4
Mounting Style	Screws
Number of auxiliary contacts as normally closed contact	1
Number of auxiliary contacts as normally open contact	0
Number of normally closed contacts as main contact	0
Number of normally open contacts as main contact	3
Number of Poles	3
Operating voltage AC 50 Hz	N/A
Operating voltage AC 60 Hz	N/A
Rated control supply voltage AC 50 Hz	N/A
Rated control supply voltage AC 60 Hz	N/A
Rated control supply voltage DC	24 - 24V
Rated operation current Ie at AC-1, 400 V	20A
Rated operation current Ie at AC-3, 400 V	8.4A
Rated operation current Ie at AC-4, 400 V	N/A
Rated operation power at AC-3, 400 V	4kW
Rated operation power at AC-4, 400 V	N/A
Rated operation power NEMA	3.677493749
Suitable for distribution board	TRUE
Terminals	Screws
Type of electrical connection of main circuit	Screw connection
Voltage type for actuating	DC
Width	36mm
