Siemens 3SE51120CR01 position Switch metal enclosure rotary actuator

Image Representative of Range

Siemens 3SE51120CR01 position Switch metal enclosure rotary actuator

Siemens
Order Code:

06-8784

Brand: Siemens MPN: 3SE51120CR01 EAN-13: 4011209692350
Qty Unit Price (Ex VAT)
1+ £51.02
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
8 in stock, despatched in 4 working days

The Siemens 3SE5112-0CR01 is a door-operated switch with a spring-loaded rod and plastic tappet for effective operation. It is rated at 6 A and offers IP65 and IP67 protection, ensuring durability in various environments. Frequently used in safety and position monitoring applications, it is suitable for industrial environments where secure switching is essential.
Type Door-operated switch
Alignment of the control element Roller cam straight
Coating housing Lacquered
Connection Screws
Construction type housing Cuboid
Contact Material Silver alloy
Degree of protection (IP) IP65
Degree of protection (NEMA) 12
Depth 37.3mm
Dim (L x W) 220.3 mm x 40 mm
Durability 1000000
Electrical lifespan 100000
Explosion safety category for dust None
Explosion safety category for gas None
Forced opening FALSE
Height of sensor 37.3mm
Housing Material Metal
Length 220.3mm
Length of sensor 220.299999999mm
Material Metal
Max. temperature +85°C
Min. temperature -25°C
Misc Attribute 3SE5112-0CR01
Number of contacts as change-over contact 0
Number of contacts as normally closed contact 1
Number of contacts as normally open contact 1
Number of safety auxiliary contacts 0
Output electronic FALSE
Rated operation current Ie at AC-15, 125 V 6A
Rated operation current Ie at AC-15, 24 V 6A
Rated operation current Ie at DC-13, 125 V 0.55A
Rated operation current Ie at DC-13, 24 V 3A
Suitable for safety functions FALSE
Switching current (max.) 6A
Switching function Quick-break switch
Switching function latching FALSE
Thread Size M20 x 1.5
Type of control element Spring-rod
Type of interface None
Type of interface for safety communication None
Width 40mm
Width sensor 40mm
With status indication FALSE
