Self Electronics SLD40-700IL-ES LED Driver CC 38.5W 700mA Dimmable

The Self Electronics SLD40-700IL-ES LED driver offers a constant current output of 700 mA and can handle loads between 30 - 55 V DC, with a maximum power of 38.5 W. It features dimmability, surge protection, and is suitable for installation on flammable surfaces, making it ideal for various LED lighting applications, including strip lights and other low-voltage LED systems. As a reliable transformer and power supply unit, it ensures optimal performance and

Type	LED driver
Connection	Screw terminal
Dim	(L x W x H) 165 x 40 x 30 mm
Height	30mm
Input voltage (max.)	264V AC
IP rating	IP20
Length	165mm
Max. output current	700mA
Max. power	38.5W
Max. temperature	40°C
Min. input voltage	198V AC
Min. temperature	-20°C
Misc Attribute	Constant current
No. of inputs	1
No. of outputs	1
Operating current	210mA
Operating voltage	230V AC
Output current (max.) - rounded	700mA
Output voltage (max.)	55V DC
Output voltage (min.)	30V DC
Power (min.)	21W
Power range	21 up to 38.5 W
Protection class	II
Test mark	Getaktet
Weight	220g
Width	40mm
