Schurter KMF1.1191.11 KMF EMI filter 250V 10A 0.40mH 50x30x47.5mm 1pc

Schurter KMF1.1191.11, also referred to as 3156877, is that serves as a robust EMI filter specifically designed for use in AC line applications requiring effective electromagnetic interference suppression. This component is rated for a voltage of 250V and a current of 10A, incorporating an inductance of 0.40mH. Its compact dimensions of 50x30x47.5mm make it a suitable choice for applications with space constraints, such as in consumer electronics, industrial automation, and medical equipment where performance reliability is paramount. The KMF1.1191.11's design ensures compliance with stringent international safety standards, making it an ideal solution for protecting sensitive electronic devices from unwanted noise and ensuring their optimal operation.

Type	EMI filter
Current Rating	10A
Content	1
Dimensions	(L x W x H) 50.00 x 30.00 x 47.50 mm
Height	47.50mm
Inductance (L)	0.40mH
IP Rating	IP40
Leakage Current	0.50mA
Length	50.00mm
Maximum Operating Temperature	85°C
Nominal Voltage	250V
Operating temperature (min.)	-25°C
Width	30.00mm
