Schnepp BU 4800 gr Safety Jack Socket 4mm Pin Green Panel-Mount 1 piece

The Schnepp BU 4800 gr is a green safety jack socket with a pin diameter of 4 mm. This connector is used commonly in laboratory settings for secure electrical connections. Its vertical orientation and safety design make it ideal for applications requiring reliable and safe connectivity.

Connector Type	Socket, straight
Plug / Socket	Socket
Mounting Direction	Straight (Panel)
Insulated	Yes
Colour	Green
Connection	Soldering
Contact Material	Brass silver plated
Insulation Material	PA
Insulation Type	Insulated
Material (details)	Insulation: PA, contact: Silver-plated brass
Nominal Current	25A
Pin Ø	4mm
Temperature Range	-10 - +50°C
Type	Safety jack socket
Voltage Rating	1000V
