Schneider Electric XPSUAT13A3AP Safety Relay 24V LED indicator 45x100x120mm

The Schneider Electric XPSUAT13A3AP safety relay operates at 24 V DC/AC and includes three makers and one breaker. It features a single LED indicator and measures 45 x 100 x 120 mm. This device is typically used in personal safety equipment, access control systems, and industrial plant safety to ensure staff protection.

Type	Safety relay
Connector	Screw terminals
Control voltage 1	24 - 24V
Control voltage 2	N/A
Depth	120mm
Dim	(W x H x D) 45 x 100 x 120 mm
Evaluation inputs	2-channel
Height	100mm
Model	Basic device
Number of outputs, safety related, delayed, semiconductors	0
Number of outputs, safety related, delayed, with contact	4
Number of outputs, safety related, undelayed, semiconductors	0
Number of outputs, safety related, undelayed, with contact	3
Number of outputs, signalling function, delayed, semiconductors	0
Number of outputs, signalling function, delayed, with contact	0
Number of outputs, signalling function, undelayed, semiconductors	0
Number of outputs, signalling function, undelayed, with contact	0
Operating Voltage	24V DC/AC
Operating voltage AC 50 Hz	24 - 24V
Operating voltage AC 60 Hz	24 - 24V
Operating voltage DC	24 - 24V
Performance level	PL e
Performance level according to EN ISO 13849-1	Level e
Power Consumption	3W
Rated switch current	0.02A
Release-delay	0 - 900s
Safety integrity level	SIL 3
Safety Rating	4
SIL according to IEC 61508	3
Stop category according to IEC 60204	0 + 1
Suitable for monitoring of emergency-stop circuits	true
Suitable for monitoring of magnetic switches	true
Suitable for monitoring of optoelectronic protection equipment	true
Suitable for monitoring of position switches	true
Suitable for monitoring of proximity switches	true
Suitable for monitoring of tactile sensors	false
Suitable for monitoring of valves	false
Suitable for rail mounting	true
Supply voltage AC 50 Hz	24 - 24V
Supply voltage AC 60 Hz	24 - 24V
Supply voltage DC	24 - 24V
Type of control voltage 1	AC/DC
Type of control voltage 2	AC/DC
Type of electric connection	Screw connection
Type of safety according to IEC 61496-1	4
Voltage type (operating voltage)	AC/DC
Voltage type (supply voltage)	AC/DC
Width	45mm
With approval according to UL	true
With approval for BG BIA	false
With approval for TÜV	true
With detachable clamps	true
With feedback circuit	true
With muting function	false
With start input	true
