Schneider Electric LA1KN31 Switch module 3 makers 1 breaker 1pc

Schneider Electric manufactures the LA1KN31 Auxiliary Switch Module, featuring three makers and one breaker for enhanced control. This module is typically used in electrical contactors to facilitate efficient operation of auxiliary circuits. Ideal for automation and control applications, it offers reliability and versatility in industrial environments.

Type	Auxiliary switch module
Connection	Screw terminal
Depth	35mm
IP Rating	IP2X
Lamp holder	N/A
Max. temperature	+50°C
Min. temperature	-25°C
Model	Clip-on
Mounting method	Front fastening
Mounting Style	DIN rail
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	1
Number of contacts as normally open contact	3
Number of fault-signal switches	0
Rated operation current Ie at AC-15, 230 V	10A
Terminals	Screw terminal
Type of electric connection	Screw connection
