Schneider Electric GV2ME02A Overload relay Circuit Breakers

Schneider Electric GV2ME02A is an overload relay intended for use in protecting and controlling electric motors. As part of the GV2 series, this device provides reliable motor protection in coordination with electrical contactors, effectively safeguarding against overload conditions. The GV2ME02A features adjustable thermal overload settings, allowing for precise adaptation to differing motor demands. Applications of this relay typically include industrial environments where motors require efficient protection, such as in manufacturing lines, machine tools, and HVAC systems. It integrates seamlessly with auxiliary contactors to offer enhanced control and protection for diverse electrical systems.

Type	GV2ME02A
Adjustment range undelayed short-circuit release	2.4-2.4A
Colour	Multicolour
Connection	Snap-in
Content	1
Depth	78.5mm
Device construction	Complete device in housing
Dimensions	(W x H x D) 45 x 101 x 78.5 mm
Height	101mm
IP Protection	IP20
IP Rating	IP20
No. of pins	3-pin
Number of Poles	3
Overload release current setting	0.16-0.25A
Phase failure sensitive	TRUE
Power loss	2.5W
Product Type	Overload relay
Rated operating voltage	690-690V
Rated operation power at AC-3, 230 V	0.037kW
Rated operation power at AC-3, 400 V	0.06kW
Rated permanent current Iu	0.25A
Rated short-circuit breaking capacity Icu at 400 V, AC	100kA
Switch off technique	Thermomagnetic
Type of control element	Push button
Type of electrical connection of main circuit	Other
Width	45mm
With integrated auxiliary switch	FALSE
With integrated under voltage release	FALSE
With thermal overload protection	TRUE
