Quadrios 23C527 Ring Terminal 6 mm² 5.3mm Hole Partially Insulated Yellow

Quadrios
Order Code:

06-3395

Brand: Quadrios MPN: 23C527 EAN-13: 4260732285168
Qty Unit Price (Ex VAT)
1+ £12.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

Quadrios manufactures the 23C527 ring terminals, which are partially insulated and ideally suited for automotive applications. These solder-free connectors feature a maximum cross-section of 6 mm² and a hole diameter of 5.3 mm, with a yellow insulation. They are typically used in car crimp terminal settings and are supplied in packs of 50.
Colour Yellow
Insulated Partially insulated
Stud Size 5.3mm
Maximum Wire Size (mm2) 6mm²
Contact Material Copper silver plated
Cross-section range 4 - 6 mm²
Hole Ø 5.3mm
max. cross section 6mm²
Maximimum Wire Gauge (AWG) 10
Min. cross section 4mm²
Product Type Ring Terminal
Thread Size M5
Voltage 600V
