PTR Hartmann manufactures the AK4551/5KD-3.5 socket housing cable, featuring five pins with a contact spacing of 3.50 mm. This component is typically used in electrical and electronic assemblies to connect and secure cables. It is suitable for precise and reliable connections in various industrial and commercial applications.
| Type |
Socket housing cable |
| AWG (min.) |
26 |
| AWG max. |
16 |
| Connector contact surface |
Tin plated |
| Connector cross section |
Up to 1.5mm² |
| Connector system |
wire-to-board |
| Connector type |
Socket, straight |
| Contact material |
Copper alloy |
| Cross section |
Up to 1.5mm² |
| CS |
3.50mm |
| Dim |
(L x W x H) 11.30 x 21.10 x 14.00 mm |
| Factory colour |
Basalt grey |
| Height |
14.00mm |
| Industrial packaging |
No |
| Length |
11.30mm |
| Manufacturer part # |
54551050401F |
| Material (details) |
PA, UL94V-0 |
| max. cross section |
2.50mm² |
| Max. temperature |
+105°C |
| Min. cross section |
0.14mm² |
| Min. temperature |
-30°C |
| Misc Attribute 1 |
Spring power terminal, plug-in |
| Misc Attribute 2 |
AK4551/5KD-3.5 |
| No. of rows |
1 |
| Nominal current |
10A |
| Nominal current - rounded value |
10A |
| Nominal current (details) |
10A |
| Nominal voltage |
300V |
| Nominal voltage (details) |
160V |
| Pins per row |
5 |
| RoHS-compliant |
Yes |
| Series |
AK(Z)4551 |
| Stripping length (max.) |
11.00mm |
| Total number of pins |
5 |
| Width |
21.10mm |
