PTR Hartmann 51550105355D STL(Z)1550 PCB Pin Housing 10 Pins 3.50mm

Image Representative of Range

PTR Hartmann 51550105355D STL(Z)1550 PCB Pin Housing 10 Pins 3.50mm

PTR
Standard range
Order Code:

06-2885

Brand: PTR MPN: 51550105355D
Qty Unit Price (Ex VAT)
1+ £0.875
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
73 in stock, despatched in 4 working days

The PTR Hartmann Pin Housing PCB STL1550/10G-3.5-V is manufactured by PTR Hartmann and features a total of 10 pins with 3.50 mm contact spacing. This component is typically used in electronic circuit boards to facilitate secure electrical connections. It is suitable for various applications in automotive, industrial, and consumer electronics.
Type Pin housing PCB
Board contact surface Tin plated
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Plug, vertical mount
Contact material Copper alloy
CS 3.50mm
Dim (L x W x H) 7.00 x 36.40 x 12.60 mm
Factory colour Basalt grey
Height 12.60mm
Industrial packaging No
Length 7.00mm
Manufacturer part # 51550105355D
Material (details) PA, UL94V-0
Max. temperature +105°C
Min. temperature -30°C
Misc Attribute 1 Pin header, vertical
Misc Attribute 2 STL1550/10G-3.5-V
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal voltage 300V
Nominal voltage (details) 160V
Pins per row 10
RoHS-compliant Yes
Series STL(Z)1550
Total number of pins 10
Width 36.40mm
