PTR Hartmann 51550085255D STL Pin Housing 8 Pins 3.50mm Spacing Top Plugging

Image Representative of Range

PTR Hartmann 51550085255D STL Pin Housing 8 Pins 3.50mm Spacing Top Plugging

PTR
Order Code:

06-2883

Brand: PTR MPN: 51550085255D EAN-13: 2050001583369
Qty Unit Price (Ex VAT)
10+ £0.676
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
Available to back orderBack order, lead time 7 weeks

The PTR Hartmann pin housing PCB STL(Z)1550 features eight pins with a contact spacing of 3.50 mm. Manufactured by PTR Hartmann, this component is ideal for securing electrical connections on a printed circuit board. It is commonly used in various electronic and industrial applications requiring reliable pin housing solutions.
Type Pin housing PCB
Number of Positions 8
Number of Rows 8
Orientation Parallel (to the PCB)
Contact Plating Tin plated
Board contact surface Tin plated
Colour Basalt grey
Connection Print
Cross Section 3.50mm
Dimensions (L x W x H) 9.20 x 29.40 x 10.50 mm
Height 10.50mm
Industrial packaging No
Length 9.20mm
Material (details) PA, UL94V-0
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 160V
Series STL(Z)1550
Width 29.40mm
