PTR Hartmann 51550075355E STL(Z)1550 Pin Housing 7 Pins 3.50mm

Image Representative of Range

PTR Hartmann 51550075355E STL(Z)1550 Pin Housing 7 Pins 3.50mm

PTR
Order Code:

06-2882

Brand: PTR MPN: 51550075355E EAN-13: 2050001583260
Qty Unit Price (Ex VAT)
10+ £0.497
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
36 in stock, despatched in 4 working days

The PTR Hartmann pin housing PCB STL1550/7G-3.5-V features seven pins with a contact spacing of 3.50 mm. This component, identified as part number 51550075355E, is typically used in electronic circuit boards for reliable electrical connections. Suitable for diverse technological applications, it aids in the efficient assembly of electronic devices.
Type Pin housing PCB
Number of Positions 7
Number of Rows 7
Orientation Perpendicular (to the PCB)
Contact Plating Tin plated
Board contact surface Tin plated
Colour Basalt grey
Connection Print
Cross Section 3.50mm
Dimensions (L x W x H) 7.00 x 25.90 x 12.60 mm
Height 12.60mm
Industrial packaging No
Length 7.00mm
Material (details) PA, UL94V-0
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 160V
Series STL(Z)1550
Width 25.90mm
