PTR Hartmann 51550075255E PCB Pin Housing 7 Pins 3.50mm Anti-Misconnection Plug

Image Representative of Range

PTR Hartmann 51550075255E PCB Pin Housing 7 Pins 3.50mm Anti-Misconnection Plug

PTR
Order Code:

06-2881

Brand: PTR MPN: 51550075255E EAN-13: 2050001583352
Qty Unit Price (Ex VAT)
10+ £0.690
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
97 in stock, despatched in 4 working days

PTR Hartmann's STL1550/7G-3.5-H is a pin housing PCB component featuring seven pins with a contact spacing of 3.50 mm. This product is ideal for electronic circuit board applications requiring reliable pin connections. It is well-suited for both consumer electronics and industrial devices.
Type Pin housing PCB
Number of Positions 7
Number of Rows 7
Orientation Parallel (to the PCB)
Contact Plating Tin plated
Board contact surface Tin plated
Colour Basalt grey
Connection Print
Cross Section 3.50mm
Dimensions (L x W x H) 9.20 x 25.90 x 10.50 mm
Height 10.50mm
Industrial packaging No
Length 9.20mm
Material (details) PA, UL94V-0
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 160V
Series STL(Z)1550
Width 25.90mm
