PTR Hartmann 51550045355F STL Pin Housing PCB 4 Pins 3.50mm Pro Plugging Face

Image Representative of Range

PTR Hartmann 51550045355F STL Pin Housing PCB 4 Pins 3.50mm Pro Plugging Face

PTR
Standard range
Order Code:

06-2878

Brand: PTR MPN: 51550045355F
Qty Unit Price (Ex VAT)
1+ £0.318
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
130 in stock, despatched in 4 working days

PTR Hartmann manufactures the Pin housing PCB STL1550 with a total of 4 pins and a contact spacing of 3.50 mm. This product, identified as STL1550/4G-3.5-V, is utilised in electronic circuit boards for secure and reliable electrical connections. It is commonly applied in industrial automation and control systems.
Type Pin housing PCB
Board contact surface Tin plated
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Plug, vertical mount
Contact material Copper alloy
CS 3.50mm
Dim (L x W x H) 7.00 x 15.40 x 12.60 mm
Factory colour Basalt grey
Height 12.60mm
Industrial packaging No
Length 7.00mm
Manufacturer part # 51550045355F
Material (details) PA, UL94V-0
Max. temperature +105°C
Min. temperature -30°C
Misc Attribute 1 Pin header, vertical
Misc Attribute 2 STL1550/4G-3.5-V
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal voltage 300V
Nominal voltage (details) 160V
Pins per row 4
RoHS-compliant Yes
Series STL(Z)1550
Total number of pins 4
Width 15.40mm
