PTR Hartmann 51550035255F STL Pin Housing PCB 3 Pins 3.50mm Spacing

PTR Hartmann manufactures the Pin housing PCB STL(Z)1550, featuring a total of three pins with a contact spacing of 3.50 mm. This component, model number 51550035255F, is ideal for use in electronic circuit board connections. It is typically applied in environments requiring reliable electrical contact and secure pin housing.

Type	Pin housing PCB
Number of Positions	3
Pitch	3.5mm
Number of Rows	3
Board contact surface	Tin plated
Colour	Basalt grey
Connection	Print
Contact Plating	Tin plated
Cross Section	3.50mm
Dimensions	(L x W x H) 9.20 x 11.90 x 10.50 mm
Height	10.50mm
Industrial packaging	No
Length	9.20mm
Material (details)	PA, UL94V-0
Maximum Temperature	+105°C
Min. temperature	-30°C
Nominal Current	10A
Nominal Voltage	160V
Orientation	Parallel (to the PCB)
Series	STL(Z)1550
Width	11.90mm
