The PTR Hartmann pin strip is a precision multi-pin connector featuring a single row of seven pins and a vertical design, finished in black. Manufactured by PTR, this component is often used in electronic applications like circuit board connections and provides reliable connectivity due to its precise pin alignment. It is well-suited for use in electronic components, connectors, and clamps, where precise and secure electrical connections are essential.
| Type |
Pin strip (precision) |
| Case material |
PA 6.6 |
| Connection |
Print |
| Connector orientation |
Perpendicular (to the PCB) |
| Connector type |
Pin strip, straight |
| Contact material |
Brass |
| Contact surface |
Tin plated |
| CS |
3.50mm |
| Dim |
(L x W x H) 2.70 x 24.50 x 12.00 mm |
| Factory colour |
Black |
| Height |
12.00mm |
| Industrial packaging |
No |
| Length |
2.70mm |
| Manufacturer part # |
51350075001G |
| Material (details) |
PA, UL94 V-0 |
| Max. temperature |
+105°C |
| Min. temperature |
-30°C |
| Misc Attribute 1 |
Multi-pin connector, vertical |
| Misc Attribute 2 |
STL1350/7-3.5-V |
| No. of rows |
1 |
| Nominal current |
9A |
| Nominal current - rounded value |
9A |
| Nominal current (details) |
8A |
| Nominal voltage |
150V |
| Nominal voltage (details) |
125V |
| Pin length (PCB) |
3.50mm |
| Pin length (receptacle) |
8.50mm |
| Pin Ø |
2.70mm |
| Pin shape |
Circular |
| Pins per row |
7 |
| RoHS-compliant |
Yes |
| Separable |
Yes |
| Total number of pins |
7 |
| Width |
24.50mm |
