PTR Hartmann 51350055001G Pin Strip Precision 1 Row 5 Pins 1pc

Image Representative of Range

PTR Hartmann 51350055001G Pin Strip Precision 1 Row 5 Pins 1pc

PTR
Order Code:

06-2869

Brand: PTR MPN: 51350055001G EAN-13: 2050000684210
Qty Unit Price (Ex VAT)
20+ £0.219
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
439 in stock, despatched in 4 working days

The PTR Hartmann pin strip is a precision multi-pin connector with one row of five pins, finished in black. It is designed for vertical installation with a 3.5 mm pitch, making it ideal for applications requiring compact and precise connectivity. Typical uses include electronic components and assemblies requiring reliable and efficient connection points.
Type Pin strip (precision)
Number of Positions 5
Number of Rows 1
Case Material PA 6.6
Colour Black
Connection Print
Connector orientation Perpendicular (to the PCB)
Contact Material Brass
Contact surface Tin plated
Cross-section range 3.50mm
Height 12.00mm
Industrial packaging No
Length 2.70mm
Material (details) PA, UL94 V-0
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 8A
Nominal Voltage 125V
Pin Length 8.50mm
Pin Ø 2.70mm
Pin shape Circular
Pins per row 5
Width 17.50mm
