PTR Hartmann 51350045001G Hartmann Pin Strip 1 Row 4 Pins Precision 1pc

Image Representative of Range

PTR Hartmann 51350045001G Hartmann Pin Strip 1 Row 4 Pins Precision 1pc

PTR
Order Code:

06-2868

Brand: PTR MPN: 51350045001G EAN-13: 2050000684203
Qty Unit Price (Ex VAT)
25+ £0.179
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
1,599 in stock, despatched in 4 working days

The PTR Hartmann pin strip (precision) is a multi-pin connector with a single row containing four pins. It features a vertical configuration with a pitch of 3.5mm, making it suitable for precise electronic connections. Typical applications include use in components, connectors, and clamps in various electronic devices.
Type Pin strip (precision)
Number of Positions 4
Number of Rows 1
Case Material PA 6.6
Colour Black
Connection Print
Connector orientation Perpendicular (to the PCB)
Contact Material Brass
Contact surface Tin plated
Cross-section range 3.50mm
Height 12.00mm
Industrial packaging No
Length 2.70mm
Material (details) PA, UL94 V-0
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 8A
Nominal Voltage 125V
Pin Length 8.50mm
Pin Ø 2.70mm
Pin shape Circular
Pins per row 4
Width 14.00mm
