PTR Hartmann 50950129021D STLZ950 Pin Housing 12 Pins 5.08mm Spacing PCB 1pc

Image Representative of Range

PTR Hartmann 50950129021D STLZ950 Pin Housing 12 Pins 5.08mm Spacing PCB 1pc

PTR
Order Code:

06-2847

Brand: PTR MPN: 50950129021D EAN-13: 2050001583901
Qty Unit Price (Ex VAT)
3+ £1.95
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
84 available to back orderBack-order availability date - 10/01/2026

PTR Hartmann manufactures the STLZ950 pin housing PCB, featuring 12 pins with a contact spacing of 5.08 mm. This component is ideal for applications requiring secure electrical connections on printed circuit boards. The pin housing is commonly used in industrial and electronic equipment for reliable signal and power connections.
Type Pin housing PCB
Number of Positions 12
Number of Rows 12
Orientation Parallel (to the PCB)
Contact Plating Tin plated
Board contact surface Tin plated
Case Material PA 6.6
Colour Green
Connection Print
Cross Section 5.08mm
Dimensions (L x W x H) 12.00 x 62.96 x 19.00 mm
Height 19.00mm
Industrial packaging No
Length 12.00mm
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 300V
Series STLZ950
Width 62.96mm
