PTR Hartmann 50950049121F STLZ950 Pin Housing PCB 4 Pins 5.08 mm Spacing

Image Representative of Range

PTR Hartmann 50950049121F STLZ950 Pin Housing PCB 4 Pins 5.08 mm Spacing

PTR
Standard range
Order Code:

06-2838

Brand: PTR MPN: 50950049121F
Qty Unit Price (Ex VAT)
1+ £0.736
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
208 in stock, despatched in 4 working days

The PTR Hartmann Pin housing PCB STLZ950 features a total of 4 pins with a contact spacing of 5.08 mm, identified by the part number 50950049121F. Manufactured by PTR Hartmann, it is designed for secure and reliable electrical connections on printed circuit boards. Typically used in electronic and electrical applications, this component ensures proper alignment and connectivity within circuit systems.
Type Pin housing PCB
Board contact surface Tin plated
Case material PA 6.6
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Plug, vertical mount
Contact material Copper alloy
CS 5.08mm
Dim (L x W x H) 8.50 x 22.50 x 22.32 mm
Factory colour Green
Height 22.32mm
Industrial packaging No
Length 8.50mm
Manufacturer part # 50950049121F
Max. temperature +105°C
Min. temperature -30°C
Misc Attribute STLZ950/4-5.08-V
No. of rows 1
Nominal current 10A
Nominal current - rounded value 10A
Nominal voltage 300V
Pins per row 4
RoHS-compliant Yes
Series STLZ950
Total number of pins 4
Width 22.50mm
