PTR Hartmann 50950039121F STLZ950 PCB Pin Housing 3 Pins 5.08 mm Spacing

PTR Hartmann 50950039121F STLZ950 PCB Pin Housing 3 Pins 5.08 mm Spacing

PTR
Order Code:

06-2835

Brand: PTR MPN: 50950039121F EAN-13: 2050001583741

Discontinued


PTR Hartmann manufactures the STLZ950 pin housing PCB with three pins and 5.08 mm contact spacing. It is identified by the product code 50950039121F. This component is typically used for secure electrical connections on printed circuit boards.
Type Pin housing PCB
Number of Positions 3
Number of Rows 3
Orientation Perpendicular (to the PCB)
Contact Plating Tin plated
Board contact surface Tin plated
Case Material PA 6.6
Colour Green
Connection Print
Cross Section 5.08mm
Dimensions (L x W x H) 8.50 x 22.50 x 17.24 mm
Height 17.24mm
Industrial packaging No
Length 8.50mm
Max. temperature +105°C
Min. temperature -30°C
Nominal Current 10A
Nominal Voltage 300V
Series STLZ950
Width 22.50mm
