PTR 51550075001E 7-Way 3.5mm 9A

Green horizontal 9A PCB connector from PTR, with 3.5mm pitch and 7 poles.

• Protection against wrong insertion by clear connector face

Body Style	Horizontal Closed End Header
Pitch	3.5mm
No of Ways Per Row	7
No. of Rows	1
Current Rating	9A
Colour	Green
Wire Gauge (AWG)	N/A
Wire Gauge (mm²)	N/A
Maximum Temperature	+105°C
Min. temperature	-30°C
Mounting Feature	PCB
Mounting Type	Pluggable
Type	Pin housing PCB
