PotentiometerRD1601F-20B4-30R6-B500K-602 Slide Potentiometer 500K Linear

Potentiometer Service RD1601F-20B4-30R6-B500K-602 is a slide potentiometer with a resistance value of 500K Ohms, designed for use as a variable resistor in electronic circuits. Its linear response characteristic allows for precision control of voltage or current, making it suitable for applications in audio equipment, instrumentation, and control systems. The part number 63250-01400-2010/B500K references its design specification, ensuring compatibility and reliability in demanding environments. The device offers excellent durability and smooth operation, critical for the fine-tuning requirements in professional audio mixers and other precision control interfaces. With its robust construction and efficient performance, this potentiometer is ideal for engineers seeking dependable components in electronics design.

Type	Single turn rotary pot
Resistance	500kΩ
Tolerance	± 20%
Power Rating	0.2W
Taper	linear
Lever Length	30mm
Axle Diameter	4mm
Connection	Print
Content	1
Maximum Temperature	+70°C
Mechanical Angle	270°
Minimum Temperature	-10°C
Output	Mono
Thread Size	M7
Tolerance ±	20%
