Potentiometer Service RD1601SF-20B4-30R6-B5K Slide Potentiometer B5K 1606345

Potentiometer Service RD1601SF-20B4-30R6-B5K is a high-precision slide potentiometer designed to function as a variable resistor, identified by the part number 1606345. This component is engineered for applications requiring precise voltage adjustment and signal control, suitable for audio equipment, professional mixers, and instrumentation panels where linear motion is required for resistance change. With a resistance value of B5K (5000 ohms), the RD1601SF-20B4-30R6-B5K offers reliable performance and durability, ensuring stability under varying environmental conditions, and features a robust build that supports smooth and consistent slide operation. The use of this slide potentiometer in engineering projects aligns well with design requirements for customisable electrical characteristics in analogue circuits.

Type	Single turn rotary pot
Resistance	5kΩ
Tolerance	± 20%
Power Rating	0.2W
Taper	linear
Lever Length	32mm
Axle Diameter	4mm
Connection	Print
Content	1
Maximum Temperature	+70°C
Mechanical Angle	270°
Minimum Temperature	-10°C
Output	Mono
Thread Size	M7
Tolerance ±	20%
