Potentiometer Service RD1601F-20FV-50R-B100K-602 Slide Pot 100K Ohm Linear

Potentiometer Service RD1601F-20FV-50R-B100K-602 is a high-precision slide potentiometer, designed as a variable resistor with a resistance of 100k ohms. This component, identified by the alternate part number 1606351 and code 65000-01600-9008/B100K, is suitable for applications requiring precise linear adjustments of electrical resistance. The slide mechanism offers smooth and accurate control, making it ideal for use in audio equipment, instrumentation panels, and other electronic devices that demand precise input modulation. Engineers can rely on its robustness and reliability in environments where consistent performance is crucial.

Type	Single turn rotary pot
Resistance	100kΩ
Tolerance	± 20%
Power Rating	0.2W
Taper	linear
Lever Length	50mm
Axle Diameter	6mm
Connection	Print
Content	1
Maximum Temperature	+70°C
Mechanical Angle	270°
Minimum Temperature	-10°C
Output	Mono
Thread Size	M10
Tolerance ±	20%
