Phoenix Contact 3240161 Blade Terminal 6.3x0.8mm Non-Insulated 100 pieces

The Phoenix Contact 3240161 is a metal blade terminal with a connector width of 6.3 mm and a thickness of 0.8 mm, designed for 180° connections. This non-insulated crimp connector is typically used in industrial applications for electrical wiring and connections. Supplied in packaging units of 100 pieces, it is ideal for bulk production environments.

Insulation	Other
Colour	Metal
Colour insulation	N/A
Connection Angle	180°
Connector thickness	0.8mm
Connector Width	6.3mm
Contact Material	Copper silver plated
Cross-section range	0.50 - 1.50mm²
For pull protected connections	true
Industrial packaging	Yes
Insulation Type	Not insulated
Material	N/A
Max. AWG-size	N/A
max. cross section	1.50mm²
Min. AWG-size	N/A
Min. cross section	0.50mm²
Misc Attribute	C-SCM 1,5/6,3X0,8
Model	N/A
Nominal cross section	0.5 - 1.5mm²
Nominal Current	N/AA
Number of branches	1
Oil stop/centre bar	false
Size	6.3 x 0.8 mm
Sleeve form	Short
Suitable for fine strand conductors	true
Suitable for flat conductors	false
Suitable for high temperatures (to 650 °C)	false
Suitable for insulated varnish	false
Suitable for round conductors	false
Suitable for solid conductors	false
Suitable for stranded conductors	true
Support sleeve	No
Surface protection	N/A
Type	Blade terminal
Type of connection	N/A
Voltage level	N/A
