Phoenix Contact manufactures the 3210509 PT 2,5-3L BU Push-in Three-level Terminal, a blue, multiport terminal designed for easy and reliable wire connection. This switchboard terminal is ideal for use in applications requiring continuity and serial connection setups. It features a push-in technology that simplifies installation, commonly utilised in control panels and electrical distribution systems.
| Pitch |
5mm |
| No. of Rows |
3 |
| Current Rating |
26A |
| Colour |
Blue |
| Wire Gauge (AWG) |
12 |
| Wire Gauge (mm²) |
4mm² |
| AWG (min.) |
26 |
| Clamp width |
5.2mm |
| Closing plate required |
true |
| Connectable conductor cross section fine-strand with cable end sleeve |
0.14 - 0.14mm² |
| Connectable conductor cross section fine-strand without cable end sleeve |
0.14 - 4mm² |
| Connectable conductor cross section multi-wired |
- - -mm² |
| Connectable conductor cross section solid-core |
0.14 - 4mm² |
| Connection |
Quick-connect |
| Cross section (flexible) (min.) |
0.14mm² |
| Cross section (inflexible) (min.) |
0.14mm² |
| Depth |
58mm |
| Dim |
(L x W x H) 102 x 5.2 x 58 mm |
| Explosion-tested version Ex e |
N/A |
| Flammability Rating |
V0 |
| Height |
58mm |
| Industrial packaging |
No |
| Inflammability class of insulation material according to UL94 |
V0 |
| Insulation |
PA |
| Insulation Material |
PA |
| Internally connected stages |
false |
| Length |
102mm |
| Material insulation body |
Thermoplastic |
| Min. stripping length |
8mm |
| Misc Attribute |
PT 2,5-3L BU |
| Mounting method |
DIN rail (top hat rail) 35 mm |
| Nominal Voltage |
500V |
| Number of clamp positions per level |
2 |
| Number of levels |
3 |
| Number of pins |
6 |
| Operating Temperature |
- - -°C |
| Rated current In |
20A |
| Rated voltage |
500V |
| Stripping length (max.) |
10mm |
| Suitable for conductor material |
Aluminium/copper |
| Type |
Multiport terminal |
| Type of electrical connection 1 |
Other |
| Type of electrical connection 2 |
Other |
| Width |
5.2mm |
