Phoenix Contact 3202902 Ferrule 0.5mm² Partially Insulated Orange 1000 pieces

Phoenix Contact's 3202902 ferrule is a 0.5 mm² partially insulated orange crimp terminal. This product, supplied in a pack of 1000, is designed to provide secure and reliable connections. It is typically used in electrical applications for terminating stranded wires to prevent fraying and ensure stable connectivity.

Insulation	Partially insulated
Colour	Orange
Pin Length	14mm
Maximum Wire Size mm2	0.5mm²
Number of Entries	1
AWG size	20
Construction type	Standard
Contact Material	Cathode copper, tin plated
Cross-section range	0.5 mm² x 8 mm
For cables resistant to short circuit	false
Halogen free	true
Insulated	true
Material	Copper
Material insulation	Other
Maximum Wire Size AWG	22
Misc Attribute	AI 0,5 - 8 OG-1000
Nominal cross section	0.5mm²
Reel/roll packaging	false
Sleeve length	8mm
Surface protection	Other
Temperature Range	+105°C
Total Length	N/Amm
Type	Ferrule
With identification flag	false
